Creating eDSLs in Haskell using the Tagless Final approach

Posted on December 15, 2020

Introduction

After watching this video, I’ve bitten the bullet and I’m down the rabbit hole learning about Free Monads and Tagless final in order to learn how to create eDSLs in Haskell.

Although following the video is of moderate complexity, actually learning to apply those concepts is more difficult. So I decided to replicate those steps as a kata exercise in order to internalize what was exposed there.

The author has a repo with all the things lined up in a final stage at Github but the code there is a bit different from what is being explained in the video, for instance the ResourceSYM doesn’t exist in the final version, so that was another reason for the kata.

This post was written in markdown and you need to install markdown-unlit to tangle the code into the GHCI interpreter. The original markdown is in the repo associated to these github pages.

$ stack exec --package lens --package mtl -- ghci -x lhs -pgmL markdown-unlit dominion.md

The problem

At 1:40 she exposes that using a card in a modern cards game involves just following a set of instructions that change the game state. You read what’s in the card and the game changes somehow. So as every programmer wants to do, she creates in the video a language describing cards in the game Dominion.

Let’s start by defining some language pragmas and importing libraries.

{-# LANGUAGE TemplateHaskell #-}
-- Required for deriving lenses
{-# LANGUAGE DeriveGeneric #-}
-- Required for constructing newtypes
{-# LANGUAGE FlexibleInstances #-}
{-# LANGUAGE GeneralizedNewtypeDeriving #-}
-- We want to use forall quantification
-- Required for using forall quantification in Int
{-# LANGUAGE QuantifiedConstraints #-}
{-# LANGUAGE RankNTypes #-}
{-# LANGUAGE RebindableSyntax #-}

module Dominion where

import Control.Lens
import Control.Monad.State hiding (modify)
import qualified Control.Monad.State as St
import Control.Monad.Trans.State.Lazy (StateT(..))
import Control.Newtype.Generics (pack, unpack)
import GHC.Generics
import Prelude hiding ((+), (-))
import qualified Prelude as P

Modeling the Festival Card

One approach to model effects in tha game is to use the StateT monad transformer holding a state for the Game and the IO monad for rendering and taking input. This is fine but you’ll face problems if you want to extend the set of cards in the future and being back compatible with existing ones (ie. the expression problem)

At 6:44 she introduces what would be the Initial Encoding approach in the original paper from Oleg Kiselov, but then she shows the problems you face when you try to extend the language with extra constructs. She says that we can overcome this extension problem by using Fixed Point encoding but she is going to turn into the Tagless encoding using Type classes.

So into the language, we will need to represent integers and operations between them:

class IntSym repr where
    lit :: Int -> repr
    (+) :: repr -> repr -> repr

When we use this language we will have something like

exp1 :: IntSym repr => repr
exp1 = (lit 1 + lit 2) + lit 3

Then if we want to extend the language to accomodate substraction we can add a new term to our language

class MinusSym repr where
    (-) :: repr -> repr -> repr

And both languages compose nicely if we add the restrictions

exp2 :: (IntSym repr, MinusSym repr) => repr
exp2 = (lit 1 - lit 2) + lit 3

Those exp1 and exp2 are just constructs in our language, they are just expressions, but we are interested in evaluating those expressions in order to produce a result. With the Tagless Final approach, creating such interpreter involves coding an interpreter in the form of an instance of those type classes for the final result we want to accomplish:

instance IntSym Int where
    lit n = n
    (+) = (P.+)

instance MinusSym Int where
    (-) = (P.-)

eval :: Int -> Int
eval = id

Then if we run our interpreter against a expression of the language:

ghci> eval expr2
2

So getting back to the Festival card at the beginning, our IntSym language is a model for Integers, so all those +2 and +1 elements of our card can be expressed between integers but we still lack terms for action, buy and gold. For that we will create our Resources language

class ResourcesSym repr where
    action :: repr
    buy :: repr
    gold :: repr

with this we can create all the lines in the card:

plusTwoActions :: (IntSym repr, ResSym repr) => repr
plusTwoActions = action + lit 2

Ok, if we want to evaluate this we cannot use the evaluators we used for the IntSym language because they don’t make any sense for the ResourceSym terms. Moreover we want to interpret this language in terms of the StateT that drives our game so we need to create a different interpreter.

But before moving to how to create the new interpreter we need to still fix the problem of how to make invalid states non representable min 11:54 (like action + action that right now are valid expressions). And as a remainder the invalidity is linked to the semantics of the language, ie. the expression lit 2 + lit 1 was a perfectly valid expressions when the semantics was the algebra of integers, but is an invalid expression when we think about how to change the state of a game. What does lit 1 + lit 2 mean in the context of chaning state of a card game?

All the sentences in the Festival card look like a modification of a resource by a function. So in order to get valid expressions we will create a language for such statements. The enforment will be done through types.

Let me create the game state that will help us run these examples (by no means this is a valid representation of the state of a game like Dominion):

data Game = Game {
    _actions :: Int
} deriving (Show)


makeLenses ''Game

For this particular example, the resources could be seen as addresses of some properties in the state of a Player. Seen in such way, for instance, we will have a definition like:

newtype GameLens a = GameLens (Lens' Game a)

class ResourceSym repr where
    action :: repr (GameLens Int)

We need to wrap the lens in a Newtype instance so we can use lenses in typeclasses. Also the pragma GeneralizedNewtypeDeriving needs to be included

This means that our repr will be a type contaning a Lens'. That lens will be a simple one that provides setters and getters from a Game type to a property of type Int (the action in this case)

So with this type we can now model in our language those sentences from the card that modify player’s state:

class StatementSym repr where
  modify :: repr (GameLens Int)
            -> (repr Int -> repr Int)
            -> repr ()

When defining interpreter instances for the StateT monad transformer we have to write

instance IntSym (State Game Int) where
    lit i = pure i
    x + y = do
      x_int <- x
      y_int <- y
      P.return (x_int P.+ y_int)

instance ResourceSym (State Game) where
  action = pure (GameLens actions)

instance StatementSym (State Game) where
  modify mlens f = do (GameLens lens) <- mlens
                      next <- f (use lens)
                      St.modify (set lens next)

With this we can create a new expression in this language of cards

plusTwoActions :: (
  ResourceSym repr,
  IntSym (repr Int),
  StatementSym repr) => repr ()
plusTwoActions = modify action (+ lit 2)

When we evaluate this language in the context of the State Game monad, we have a real State Game monad ready to being executed or unrolled. Let’s see how to get that:

-- Our interpreter
eval :: State Game a -> State Game a
eval = id

initialGame :: Game
initialGame = Game { _actions = 0 }

modifiedGame = execState (eval plusTwoActions) initialGame

And you can check that modifiedGame is Game { _actions = 2 }.

Conclusion

I was first exposed to the Tagless Final approach in the excellent series of posts Real World Halogen. The author uses type classes to model capabilities of the application (creating logs, writing to a DB) with the benefit that later the actual implementations (ie. the interpreters) can change at will. Another benefit is testing, you don’t need mocking libraries like in other programming languages, you just swap the intepreter by another one where effects are fully controlled.

Free monads and tagless final are kind of equivalent and interchangeable, you could even use them in different parts of your program without any problem, but from what I’ve been reading people think that tagless final is superior (see for instance this talk). But at the same time I’m currently reading Functional Design and Architecture were free monads are the core of all designs and I’ve also discovered Polysemy that promises to remove all the bolierplate code associated with Free Monads and get the benefits of having you eDSL in memory.

So for now I will go for the Tagless Final approach although I’ll keep an eye on Polysemy and Free Monads.
